產品名稱：DHD-1313 產品應用：測試1
-
Drill Depth 1100mm 3 Axis CNC Machine for Deep Hole Drilling DH-1100
Intergrated base structure, good stability, simple operation, reasonable layout, mold and covenient aeesmbly and disassembly, wide application.
Suitable for most mold processing.
Model NO.DH-1100Process UsageMetal-Cutting CNC Machine ToolsMovement MethodLinear ControlControl MethodClosed-Loop ControlNumerical ControlCNC/MNCProcessing Precision0.01~0.02(mm)Performance ClassificationHigh-End CNC Machine ToolsCertificationGS, CE, RoHS, ISO 9001ConditionNewInner Diameter of Drilling2.5-30mmMaximum Depth of Drilling1100mmSize of Working Table1200*800mmX-Axis Travel1100mmY-Axis Travel800mmZ-Axis Travel1100mmDrilling Cutting Feed Rate1-300mm/MinMaximum Rotating Speed of Spindle7000rpmPrincipal Axis Motor7.5/11kwThree Axis Motor2.3/3/2.3kwPressure of Oil Pump0-150kg/CmCapacity of Cutting Oil Tank800LLoad Capacity of Working Table8000kgMachine Net Weight10000kgMachine Size4800*3800*2800mmTransport PackageExported PackagesSpecification4800*3800*2600mmTrademarkJOINTOriginChinaHS Code8459210000Production Capacity1000
